The word Mojo refers to a magic spell or charm, and more broadly, a magical power. Since its introduction in 1994, the Mojo has delivered a wicked combination of fun and all-mountain prowess.
The Mojo V4 features a 76.6-degree, get-you-up-that-hill seat tube angle, our shortest chainstays, and a spacious reach with a 65.4-degree headtube angle. This enchanting combination rolls on 27.5" wheels to deliver that hoverbike feel with on-trail confidence.
Since 2005, we've partnered with suspension guru, Dave Weagle, on the dw-link suspension platform. It provides an unparalleled combination of climbing efficiency and downhill performance, which has been proven repeatedly at the highest levels of racing.
Our custom-tuned suspension features extra-light high-speed compression and rebound damping to deliver unparalleled traction. When paired with our dw-link suspension platform, Traction Tune allows the Mojo to track like a big bike without compromising crisp pedaling performance.
PICK YOUR SIZE
All four sizes have low standover heights and shortened seat tubes for long dropper posts. Now you can choose your frame based on reach-riders 5-feet tall easily fit on a small and still enjoy a 125mm dropper, while most medium and up riders can enjoy a 185mm. All sizes fit a water bottle, and those looking to go packless can run our aftermarket Pork Chop bag.
Reduced-offset forks give the front wheel greater stability at speed and an additional sense of steadiness at slow speeds too. The Mojo is designed to excel in technical, demanding terrain, and the 37mm-offset gives that extra bit of confidence and control in the most challenging situations.
The Mojo has clearance for 27.5"x2.6" tires. You can run overbuilt, chunky tires; you can run light, big volume fast tires, but whatever you run, know that you're not limited by width.
Tired of hitting "purchase" on another set of bearings each season? So were we. That's why we use bushings where they make sense, and bearings where they don't. The IGUS bushings in our lower link are lighter and stiffer than bearings and are virtually maintenance-free. We believe so strongly in them, we back them with a free lifetime replacement.
LIGHTWEIGHT PREMIUM CARBON FOR EVERYONE
All our bikes are built from the highest-grade materials and optimized for the best strength, weight, stiffness, and ride performance-no matter how much you spend. The Mojo weighs a svelte 5.9 lbs with an inline shock, and complete builds start at 26.7 lbs.
INTERNAL CABLE ROUTING
Bikes that look pretty on the outside should look pretty on the inside. We use carbon fiber tubes molded within each frame. Push the cable in, watch it pop out, a beautiful moment indeed.
REMOVABLE ISCG MOUNT
There if you want it, removable if you don't.
PROTECT YOUR INVESTMENT
A polycarbonate downtube protector deflects debris, while molded rubber swing arm protectors keep things quiet and clean. And, our simple-yet-elegant linkage protectors stop mud and rocks thrown by the tire, keeping your beautiful bike beautiful.
|D. Effective Top Tube||580mm||603mm||632mm||666mm|
|E. Head Tube Angle||65.4°||65.4°||65.4°||65.4°|
|F. Head Tube Length||109mm||126mm||142mm||158mm|
|G. Seat Tube Angle||76.6°||76.6°||76.6°||76.6°|
|H. Seat Tube Length||360mm||368mm||419mm||470mm|
|I. Bottom Bracket Height||340mm||340mm||340mm||340mm|
|O. Chainstay Length||425mm||425mm||425mm||425mm|
|Fork||Rock Shox Pike Ultimate RC2 140mm, 27.5", 110x15|
|Rear Shock||Fox Float Factory Series, DPS with EVOL, 210 x 50 S/M: Light Tune, L/XL: Standard|
|Wheels||Select from the dropdown above|
Front: Schwalbe Hans Dampf 27.5 x 2.6" Addix Soft Super Trail
Rear: Schwalbe Nobby Nic 27.5 x 2.6" Addix Speedgrip Super Trail
|Bottom Bracket||Shimano XT MT800|
|Crankset||Shimano XT M8100, 30t Alloy Ring S/M: 170mm, L/XL: 175mm|
|Shifters||Shimano XT M8100, 12 speed|
|Rear Derailleur||Shimano XT M8100 Shadow Plus 12 speed|
|Cassette/Freewheel||Shimano XT, 10-51|
|Chain||Shimano XT M8100, 12 speed|
|Brakes||Shimano XT M8120, 4 piston|
|Rotors||Shimano SM-RT86, 180mm|
|Handlebars||Ibis 800mm Hi Fi Bar|
|Tape/Grips||Lizard Skin Charger|
|Stem||Industry Nine A318 S/M: 40mm, L/XL: 50mm|
|Headset||Cane Creek 40 ZS44/ZS56|
|Seatpost||Bike Yoke Revive Dropper S: 125mm, M: 160mm, L/XL: 185mm. Note there is a 250lb rider weight limit on this post.|
|Saddle||WTB Silverado 142|
* Subject to change without notice.
